HI2020-02
|
|
بازهpH
|
pH: -2.000 to 16.000, -2.00 to 16.00; ±1000 mV
|
|
رزولوشنpH
|
0.001 pH, 0.01 pH; 0.1 mV
|
|
دقت pH
|
±0.01 pH, ±0.002 pH; ±0.2 mV
|
|
کالیبراسیونpH
|
Automatic, up to 3 points (5 points*) calibration, 5 standard (7 standard*) buffers available (1.68*, 4.01 or 3.00, 6.86, 7.01, 9.18, 10.01, 12.45*) and 2 custom buffers*
|
|
جبران دماییpH
|
Automatic -5 to 100˚ C (23 to 212˚ F) (using integral temperature sensor)
|
|
بازهEC
|
0.00 to 29.99 μS/cm, 3.00 to 29.99 μS/cm, 30.0 to 299.9 μS/cm, 300 to 2999 μS/cm, 3.00 to 29.99 mS/cm, 30.0 to 200.0 mS/cm, up to 500.0 mS/cm
|
|
رزولوشنEC
|
0.01 μS/cm, 00.1 μS/cm, 0.01 μS/cm, 0.01 mS/cm, 00.1 mS/cm
|
|
دقتEC
|
±1% of reading (±0.05 μS/cm or 1 digit, whichever is greater)
|
|
کالیبراسیونEC
|
1 Cell Factor calibration; 6 standards available: 84, 1413 μS/cm, 5.00, 12.88, 80.0, 111.8 mS/cm, 1 point offset: 0.00 μS/cm
|
|
بازهTDS
|
0.00 to 14.99 ppm (mg/L), 15.0 to 149.9 ppm (mg/L), 150. to 1499. ppm (mg/L), 1.50 to 14.99 g/L, 15.0 to 100.0 g/L, up to 400.0 g/L absolute TDS ‡ (with 0.80 factor)
|
|
رزولوشنTDS
|
0.01 ppm, 0.1 ppm, 1 ppm, 0.01 g/L, 0.1 g/L
|
|
دقتTDS
|
±1% of reading (±0.03 ppm or 1 digit, whichever is greater)
|
|
کالیبراسیونTDS
|
through EC calibration
|
|
جبران دماییEC/TDS
|
Automatic -5 to 100 ºC (23 to 212 ºF) NoTC – can be selected to measure absolute conductivity.
|
|
ضریب تصحیح دما
|
0.00 to 6.00% / ºC (for EC and TDS only). Default value is 1.90% / ºC
|
|
فاکتور تبدیلEC به TDS
|
0.40 to 0.80 (default value is 0.50)
|
|
محدوده شوری
|
0.0 to 400.0% NaCl, 0.01 to 42.00 PSU, 0.0 to 80.0 g/L*
|
|
رزولوشن شوری
|
0.1% NaCl, 0.01 PSU, 0.01 g/L
|
|
دقت شوری
|
±1% of reading
|
|
کالیبراسیون شوری
|
1 point with HI 7037L 100% NaCl sea water standard (other scales through EC calibration)
|
|
جبران دمایی شوری
|
0 to 40 g/L (with 1 g/L resolution)
|
|
محدوده نمک سدیم کلرید
|
0.0 to 400.0% NaCl
|
|
رزولوشن سدیم کلرید
|
0.1% NaCl
|
|
دقت اندازه گیری نمک
|
±1% of reading
|
|
کالیبراسیون سدیم کلرید
|
1 point with HI 7037L 100% NaCl sea water standard (other scales through EC calibration)
|
|
بازهDO
|
0.00 to 45.00 ppm (mg/L) 0.0 to 300.0% 0.0 to 50.0 °C (32.0 to 122.0 °F)**
|
|
دقت اندازه گیری DO
(در 25 درجه سانتی گراد)
|
±1.5% of reading or ±1 digit
|
|
رزولوشنDO
|
0.01 ppm (mg/L); 0.1% saturation
|
|
کالیبراسیون اکسیژن محلول
|
One or two points at 0% (HI 7040) and 100% (water saturated air)
|
|
جبران دماییDO
|
0.0 to 50.0 ˚C (32.0 to 122 ˚F)
|
|
جبران شوری
|
0 to 40 g/L, 1 g/L
|
|
جبران ارتفاعDO
|
-500 to 4000 m (with 100 m resolution)
|
|
بازه اندازه گیری دما
|
-20.0 to 120.0 ˚C, -4.0 to 248.0 °F
|
|
رزولوشن دما
|
0.1 °C, 0.1 °F
|
|
دقت دما
|
±0.5 °C, ±1.0 °F
|
|
pH الکترود
|
HI11310 glass body, refillable pH electrode with temperature sensor
|
|
پروبEC/TDS
|
HI763100 EC/temperature probeᵻ
|
|
پروبDO
|
HI764080 DO/temperature probeᵻ
|
|
منبع تغذیه
|
5 VDC adapter (included)
|
|
شرایط محیطی
|
0 to 50°C (32 to 122°F), RH max 95% non-condensing
|
|
ابعاد
|
202 x 140 x 12.7mm (8” x 5.5” x 0.5”)
|
|
وزن
|
250 g (8.82 oz)
|
